PHYSICAL PROPERTIES | |
Property | Typical Value | Test Method |
Density | 905kg/m3 | ISO 1183 |
Melt Flow Rate (230°C/2.16kg) | 0.30g/10min | ISO 1133 |
Flexural Modulus (2mm/min) | 850MPa | ISO 178 |
Tensile Modulus (1mm/min) | 800MPa | ISO 527 |
Tensile Strain at Yield (50mm/min) | 13.5% | ISO 527-2 |
Tensile Stress at Yield (50mm/min) | 25MPa | ISO 527-2 |
Thermal Conductivity | 0.24W/(m K) | DIN 52612 |
Coefficient of Thermal Expansion (0°C/70°C) | 1.8*10E-4/K | DIN 53752 |
Charpy Impact Strength, notched (23°C) | 60 kJ/m² | ISO 179/1eA |
Charpy Impact Strength, notched (0°C) | 6.0kJ/m² | ISO 179/1eA |
Charpy Impact Strength, unotched (23°C) | No break | ISO 179/1eU |
Charpy Impact Strength, unotched (0°C) | No break | ISO 179/1eU |
*Data should not be used for specification work | | |
