Xinfa PVC Resin

Xinfa PVC resin is a synthetic resin widely used in plastic production. It is usually in white powder form and is polymerized by suspension method. Its main component is polyvinyl chloride (PVC), which has the characteristics of abundant raw materials, mature manufacturing technology and low price. Of course, there will be certain differences in prices in different regions and for different models. If you need to know the price of Xinfa PVC, please contact us for the latest quotation.

Main Models and Uses of Xinfa PVC Resin

PVC SG-3 is mainly used to produce general-purpose soft products such as films, hoses, leather, wires and cables.
PVC SG-5 is suitable for manufacturing pipes, pipe fittings, plates, calendered products, injection molded products, profiles and sandals.
PVC SG-7/SG-8 is often used to produce bottles, sheets, calendered products, hard injection and molded pipes, etc.

Item		SG3	SG5	SG7	SG8
Viscosity No. ml/g		135-127	118-107	95-87	86-73
K value		72-71	68-66	62-60	59-55
Polymerizing Index		1370-1251	1135-981	845-741	740-650
Number of impurity particles		16max	16max	20max	20max
Volatile Matter, %		0.3max	0.4max	0.4max	0.4max
Apparent Density, g/ml		0.45min	0.48min	0.50min	0.50min
Number of Fish Eye (/400 cm2)		20max	20max	30max	30max
Plasticizer absorption of 100g resin, g		26min	19min	12min	12min
VCM Residue, ppm		5max	5max	5max	5max
Whiteness(160°C,10min), %		78min	75min	75min	75min
Particle size	≥0.25mm	2.0max	2.0max	2.0max	2.0max
Particle size	≥0.063mm	95min	95min	95min	95min
Main applications	leathers, hoses, wire cables, shoes and other general purpose soft products.		pipes, profiles, fittings, panels, injection, moulding, sandals, hard tube and decorative materials,etc.	sheets, bottles, calendaring, rigid injection molding and molded pipes.

Performance Characteristics

Good chemical stability. The resin has high chemical resistance, water resistance, wear resistance, and is not easily corroded by general chemicals. It can be used in a variety of chemical environments.
Good insulation. It is non-conductive and can be used as an insulating material for wires and cables, which can effectively ensure the safety of electricity use.
Thermoplasticity. Xinfa PVC can be softened by heat and hardened after cooling. It can be made into plastic products of various shapes through various processing methods such as molding, lamination, injection molding, extrusion, calendering, and blow molding.
Good mechanical properties. Rigid PVC (without plasticizer added) has good mechanical strength and can be used to manufacture products such as pipes, door and window profiles that require strength.
Flame retardancy. This resin has a certain flame retardancy and is easy to extinguish after leaving the flame, which improves the safety during use.
